item no.:
TPU-NA-LGFPayment:
Discussedproduct origin:
ChinaColor:
Natural color or Customizedshipping port:
XiamenLead Time:
2-10 working days
Characteristic |
Unit |
Test Method |
Property Value |
Specific Gravity |
g/cm³ |
ASTM D-792 |
1.51 |
Molding Shrinkage |
% |
ASTM D-955 |
|
Tensile Strength |
MPa | ASTM D-638 | 220 |
Tensile Modulus |
MPa | ASTM D-638 | 11720 |
Tensile Elongation |
% |
ASTM D-638 |
2.0-3.0 |
Flexural Strength |
MPa | ASTM D-790 | 310 |
Flexural Modulus |
MPa | ASTM D-790 | 9650 |
Notched Izod Impact |
KJ/m2 |
ASTM D-256 | 569 |
Notched Charpy Impact |
KJ/m2 |
ASTM D-4812 |
1469 |
Deflection Temperature |
°C |
ASTM D-648 |
|
For reference only
Why choose LFT Materials?
Long glass fiber reinforced composites can solve your problems when other methods of reinforced plastics do not provide the performance you need or if you want to replace metal with plastic. Long glass fiber reinforced composites can cost-effectively reduce the cost of goods and effectively improve the mechanical properties of engineering polymer .Long fibers can be uniformly distributed inside the product to form a network skeleton, thus improving the mechanical properties of the material product.
Long fiber reinforced thermoplastics properties
- Strong yet ductile fiber option
- Exceptional toughness retained at low and elevated temperatures
- High fatigue and creep endurance
- Mechanical property retention at low and elevated temperatures
- Colorable for product branding or quick identification
- Go-to material for metal replacement with favorable economics
- Greater properties than short fiber/chopped glass fiber filled compounds
Key Long Fiber Reinforced Thermoplastics Uses:
- Auto interior trim
- Automotive engine compartment covers
- Car chassis
- Car engine
- Consumer goods
- Enclosure and frame
- Furniture
- Medical
- Power tools
- Sport
- EBikes
Xiamen LFT has capabilities to provide assistance to you throughout an entire product launch - through product discussion, performance analysis, composite selection, composite pellet production, after-sales tracking. In addition, we provide guidance on injection molding techniques
